Subminiature Power-D

One Power-D CF feedthrough Show CF Feedthroughs for One Power-D CF feedthrough
CF Feedthroughs
One Power-D ISO feedthrough Show ISO KF / LF Feedthroughs for One Power-D ISO feedthrough
ISO KF / LF Feedthroughs
3 power male and female Power-D cables Show UHV Cables for 3 power male and female Power-D cables
UHV Cables
One 3 power and one 5 power female Power-D PEEK connectors and 5 power contacts Show UHV Components for One 3 power and one 5 power female Power-D PEEK connectors and 5 power contacts
UHV Components
One 5 power male Power-D air cable Show Air Cables / Components for One 5 power male Power-D air cable
Air Cables / Components
Subminiature Power-D Feedthrough Drawing

Subminiature Power-D Feedthroughs

Power hermetic Subminiature-D feedthroughs are power contact combinations constructed with pin arrangements designed to meet IEC 807-2 and DESC 85039 specifications.

Standard configurations include power pins in a single Subminiature-D shell. Straight through pins are hermetically sealed and electrically insulated in a stainless steel shell using the latest in glass-ceramic bonding technology. Ultrahigh vacuum cable assemblies with PEEK connectors and Kapton® insulated wires are available to meet the demands of UHV environments.

pdf iconCatalog Page
