Mil-C-5015 Circular Feedthroughs and Accessories

Two Mil-C-5015 CF feedthroughs Show CF Feedthroughs for Two Mil-C-5015 CF feedthroughs
CF Feedthroughs
Two Mil-C-5015 ISO feedthroughs Show ISO KF / LF Feedthroughs for Two Mil-C-5015 ISO feedthroughs
ISO KF / LF Feedthroughs
2 female connector to cables and 2 male connector to connectors Show UHV Cables for 2 female connector to cables and 2 male connector to connectors
UHV Cables
2 female connectors, 1 male connector, 2 female and 2 male T-5p power contacts Show UHV Components for 2 female connectors, 1 male connector, 2 female and 2 male T-5p power contacts
UHV Components
2 3C and 6C female air connector to cables Show Air Cables / Components for 2 3C and 6C female air connector to cables
Air Cables / Components
Power Feedthrough Mil-C-5015 Feedthrough Drawing

Mil-C-5015 Feedthroughs

Accu-Glass Products' circular hermetic power feedthroughs are designed to meet Mil-C-5015 specifications.  These circular feedthroughs are available in either a 3-pin or 6-pin configuration.  Gold plated pins are in a straight through pin-to-pin design, are hermetically sealed, and electrically insulated in a stainless steel shell using the latest in glass-ceramic bonding technology.

Ultrahigh vacuum cable assemblies with PEEK (polyetheretherketone) connectors and Kapton® insulated 18 AWG cables are available to meet the demands of UHV environments.  They are fitted with a captured stainless steel vented screw that provides a means of securely locking them to their mating feedthrough.  Air service cable assemblies use standard Mil-C-5015 connectors.  Custom vacuum and air-service cable assemblies are available on request.

CLICK ON A CATEGORY BELOW TO SEE OUR AVAILABLE PRODUCTS FOR PURCHASE.

pdf iconCatalog Page
