4 Pairs of Thermocouple Feedthrough on a KF40 CF Flange
Part Number: 100791
D-Type Feedthrough, Consisting of 4 Thermocouple Pairs of Pins on a KF40 Flange.
$377.00
This is a test of the "site alert message system". (edited)
Thermocouple (TYPE-K) ISO Feedthrough Flanges
2 Pairs of Thermocouple pins and two Power Pins Feedthrough - KF50
Part Number: 100801
D-Type Feedthrough, Consisting of 2 Thermocouple Pairs of Pins and 2 Power Pins on a KF50 Flange.
$410.00
Type-K ISO Thermocouple Feedthroughs
These ISO thermocouple feedthroughs are mounted on KF Flanges that incorporate the industry standard "Quick Release Hinged Clamp", making it easy to mount/demount to your existing KF Flange ports.
Features
Subminiature-D Interface
• Type-K Chromel®/Alumel® pins
• 4 TC-pairs / 2 TC-pair and 2 power leads
• High temperature rated to 150°C
• UHV compatible construction
• ISO NW compatible KF mounts
• Kapton® insulated vacuum cables
• PEEK Connector with locking screws
• Air service cables / connectors
• Custom solutions on request
