4 Pairs of Pins - Thermocouple Feedthrough on a 2.75" CF Flange
Part Number: 100790
D-Type Feedthrough, Consisting of 4 Thermocouple Pairs of Pins on a 2.75" CF Flange.
$384.00
This is a test of the "site alert message system". (edited)
Thermocouple (Type-K) CF Feedthrough Flanges
4 Pairs of Pins - Thermocouple Feedthrough on a 4.50" CF Flange
Part Number: 112709
D-Type Feedthrough, Consisting of 4 Thermocouple Pairs of Pins on a 4.50" CF Flange.
$414.00
2 Pairs of Thermocouple pins and two Power Pins Feedthrough
Part Number: 100800
D-Type Feedthrough, Consisting of 2 Thermocouple Pairs of Pins and 2 Power Pins on a 4.50" CF Flange.
$455.00
Type-K CF Thermocouple Feedthroughs
These CF thermocouple feedthroughs are mounted on CF Flanges that incorporate the industry standard "captured copper gasket" sealing principle, making it easy to mount to your existing CF Flange ports.
• Subminiature-D Interface
• Type-K Chromel®/Alumel® pins
• 4 TC-pairs / 2 TC-pair and 2 power leads
• High temperature rated to 250°C
• UHV compatible construction
• Conflat® compatible mounts
• Kapton® insulated vacuum cables
• PEEK Connector with locking screws
• Air service cables/connectors
• Custom solutions on request
